Connect the black test lead to the COM jack and the red test lead to the ma/cx jack for a maximum of 300mA. The polarity of the red connection will be indicated when making a dc voltage measurement. Set the rotary switch at the desired V or V ~ range position and connect test leads across the source or load under measurement. Connect the black test lead to the COM jack and the red test lead to the V/ /F jack. OPERATING INSTRUCTION 3.1 MEASURING VOLTAGE 1. During use, connect the black test lead to the COM jack and red test lead as shown below: Function Red lead connection Input limits DCV/ACV V/ /F 1000V dc or 750V rms ac khz V/ /F 250V dc or rms ac / / V/ /F 250Vdc or rms ac μa/ma ma/cx 300mA dc or rms ac nf/μf ma/cx 300mA fuse protected A A 10A dc or rms ac μa/ma and A ranges are protected by fusesĨ 3. 2.4 INPUT JACKS This meter has four input jacks that are protected against overload to the limits. Push this button to select / measuring function when the function switch is set at / positions. 2.3 AC/DC CURRENT OR / SELECTING Button Push this button to select AC or DC current measuring function when the function switch is set at μa, ma, A positions. Data holding will be canceled automatically when the function switch is rotated. Push this button as following to shoose range control mode and desired rangesħ 2.2 DATA HOLD BUTTON When this button is pushed, the display will show the last reading and D-H symbol will appear until pushing it again.
#Kal equipment 3000 multimeter manual portable
DESCRIPTION This meter is a portable professional measuring instrument with 3 1/2 digit LCD, capable of performing functions: DC and AC voltage measurement DC and AC current measurement Resistance measurement Capacitance measurement Diode test Transistor test Audible continuity test Frequency measurement NAMES OF COMPONENTS 1 Range control button 2 Data hold button 3 LCD display 4 AC/DC current or / selecting button 5 Socket for transistor test 6 Rotary switch/power switch 7 V/ /F input jack 8 COM input jack - 3 -Ħ 9 ma/cx input jack 10 10A input jack 2.1 RANGE CONTROL BUTTON Range for AC/DC voltage, AC/DC current (μa and ma only), resistance and frequency measuring can be selected manually or handled by autoranging. To clean the meter, use a damp cloth and mild detergent only, do not use abrasives or solvents on it. For continue protection against fire, replace fuse only with the specified voltage and current ratings: F1: F 300mA/250V F2: F 10A/250V If any faults or abnormalities are observed, the meter can not be used any more and it has to be checked outĥ Never use the meter unless the back cover is in place and fastened fully. Earth ground Double insulation (Protection class ) 1.4 MAINTENANCE Before opening the meter, always disconnect test leads from all sources of electric current. 1.3 SYMBOLS Important safety information, refer to the operating manual. Keep fingers behind the probe barriers while measuring. Always be careful when working with voltages above 60V dc or 30V ac rms. Never perform resistance measurements on live circuits.
#Kal equipment 3000 multimeter manual tv
When carrying out measurements on TV or switching power circuits, always remember that there may be high amplitude voltages pulses at test points which can damage the meter. Before rotating the range selector to change functions, disconnect test leads from the circuit under - 1 -Ĥ test. When the value scale to be measured is unknown beforehand, set the range selector at the highest position. When the meter is linked to measurement circuit, do not touch unused terminals. 1.2 DURING USE Never exceed the protection limit values indicated in specifications for each range of measurement. Measuring leads must be in good condition. If necessary, they must be replaced with the same model or same electronic ratings.
#Kal equipment 3000 multimeter manual full
Full compliance with safety standards can be guaranteed only if used with test leads supplied. 1.1 PRELIMINARY When using this meter, the user must observe all normal safety rules concerning: Protection against the dangers of electrical current. Follow all safety and operating instructions to ensure that the meter is used safely and is kept in good operating condition. SAFETY INFORMATION This multimeter has been designed according to IEC 1010 concerning electronic measuring instruments with an overvoltage category ( CAT ) and pollution 2.
SPECIFICATIONS ACCESSORIES BATTERY & FUSE REPLACEMENT.14ģ 1. OPERATING INSTRUCTION Measuring voltage Measuring current Measuring frequency Measuring resistance Measuring capacitance Testing diode & continuity Testing transistor 9 4.
